Hydraulic offset mowing for 40-70 HP tractors
Clear big paddocks, orchard rows and estate verges in fewer passes - the side-shift A-frame reaches under hedges and around trees from the seat. The Winton W‑HF220 runs a 2.2m hydraulic-offset deck on a compact tractor for owner-operators on heavy work.
OverviewEssential Winton W‑HF220 Flail Mower info
Mower Position Hydraulic Sideshift
Tractor HP40 - 70 hp
Cutting Width 220 cm
Weight 500 kg
Free PTO Shaft Included
Free Delivery Included
DescriptionWhy buy the Winton W‑HF220 Flail Mower?
The W-HF220 is the largest mower in Winton's hydraulic-offset flail family. At 2.2m it clears big paddocks, orchard alleys and estate verges in noticeably fewer passes than the smaller siblings, and the hydraulic side-shift lets you reach under hedgerows or around trees without dropping a wheel into the cut.
Built for 40–70 HP tractors
This is the heaviest machine in the range at 500 kg, mounted on Cat 1 three-point linkage and PTO driven through 4 belts to the rotor shaft. Smaller compacts won't drive it — match it to a tractor with the lift capacity and PTO to suit.
Overgrowth one week, finer finish the next
36 hammer-style flails sit in a spiral pattern around the rotor. They bite through tall grass, weeds and light scrub, and when the same deck is run regularly over managed grass at the 3 cm setting it leaves a fine finish suitable for sports field margins or larger lawns.
Height control and ground-following
Cutting height adjusts from 3–8 cm via the rear roller and twin skids. The roller also helps the mower ride uneven ground without scalping — useful where a rotary topper would gouge.
- 2.2m working width — widest in the W-HF family, fewer passes on big acreage
- Tractor range 40–70 HP; 500 kg; Cat 1 three-point linkage
- Hydraulic side-shift A-frame — 1 double-acting spool required
- 36 hammer-style flails on a spiral rotor
- Cutting height 3–8 cm via adjustable rear roller and twin skids
- Belt-driven rotor with 4 drive belts to the blade shaft
- Lower linkage width 77–92 cm
- Offset reach for hedgerows, fence lines and tree surrounds
SpecificationsWinton W‑HF220 Flail Mower technical details
Brand
Winton Machinery
Reference (SKU)
W‑HF220
Weight
500kg
Working Width
220cm
Tractor HP Required (range)
40-70hp
Cutting Heights
3-8cm
Number of Blades
36
Linkage Type
Category 1
Oil Type
Gear 80W90
Min. Hydraulic Fittings
1x Double Acting Spool
PTO Shaft
Included FREE of charge
Warranty
12 months manufacturer's warranty
FeaturesWinton W‑HF220 Flail Mower features & benefits
High Density Vegetation
Winton flail mowers are designed to power through thick brambles, dense weeds, saplings and long grass. They can also leave a neat finish on regularly cut grass.
Professional Use
Professional-grade machines are built tough and use premium components. In additional to being exceptionally reliable, they achieve great results and are very efficient.
Strong & Simple to Maintain
The chassis is constructed from thick steel and is built to be easy to maintain and repair. They feature higher quality bearings, blades and gearboxes over many rival models.
Heavy Duty Gearbox
Winton gearboxes are heavy-duty and robustly made. They are highly reliable and significantly larger than other machines in their price bracket, allowing more power to be transferred through them.
Heavy Hammer Flails
The heavy hammer blades are arranged spirally for an efficient cut. These blades will smash through dense vegetation and brambles and also give you a neat finish on fine grass when used regularly.
Tractor CompatibilityCheck tractor fit for the Winton WHF series
Compatibility is based on standard tractor specifications, such as a 540RPM clockwise PTO, Type 1 or 2 linkage, and hydraulic spools where required.
ReviewsVerified Winton W‑HF220 Flail Mower reviews
5 reviews for the Winton W‑HF220 Flail Mower
25 reviews for all WHF Flail Mower models
Review Your Winton W‑HF220
Heavy duty flail for a great price and the offset capability really speeds up the cut round the headlands
Fantastic service
Fantastic service! My new Winton 2.2m flail was delivered promptly and for a great price. Thanks!
Well worth the money
Competitive pricing, responsive pre-sales and good after sales…
Competitive pricing and responding quickly to my queries to confirm the product was suitable to my needs, made the purchasing decision simple. Once ordered, the mower was shipped quickly. What secured the 5 stars was the quick response and resolution, not only by Zaros Machinery but also by Winton to replace a hydraulic hose with one that was the correct length to fit my tractor.
