Seedbed prep for 36-60 HP compact tractors on Cat 1
Cover more ground per pass on bigger seedbeds and work down to 15 cm in a single run. Wider than its sibling, the Winton W‑PH170 sits behind a compact tractor - built for landscapers and smallholders prepping more than a 1.3m can manage in a day.
OverviewEssential Winton W‑PH170 Power Harrow info
Machine Type Power Harrow
Tractor HP36 - 60 hp
Working Width 170 cm
Penetration Depth 15 cm
Weight 345 kg
Free PTO Shaft Included
Free Delivery Included
DescriptionWhy buy the Winton W‑PH170 Power Harrow?
The 1.7m working width is the headline here. The W-PH170 is the wider model in Winton's harrow line, pitched at landscapers and allotment holders who want to clear bigger plots in fewer passes. Run it behind a compact tractor in the 36–60 HP range on a Cat 1 three-point linkage.
Seedbed in one pass
The blades bite to a 15 cm working depth, breaking up compacted ground and aerating the soil so it warms earlier in the season. Behind them, the rear mesh roller levels the tilth into a finished seedbed ready for seeding or turfing. Best suited to grassless, low-stone areas — not rocky ground.
Build and safety
16 blades sit on separate carriers for working efficiency. Drive comes through a shear-bolt PTO shaft, which protects the driveline if the harrow is overworked. If you'd rather not replace shear bolts every time you hit a hard patch, the optional slip clutch PTO upgrade is worth a look.
- 1.7m working width for clearing bigger seedbeds in one pass
- 36–60 HP tractor range on a Cat 1 three-point linkage
- 15 cm maximum working depth for a proper seedbed
- 16 blades on separate carriers for working efficiency
- Rear mesh roller levels and finishes the tilth in the same pass
- Shear-bolt PTO shaft included as standard
- Optional slip clutch PTO upgrade available
- 345 kg working weight
SpecificationsWinton W‑PH170 Power Harrow technical details
Brand
Winton Machinery
Reference (SKU)
W‑PH170
Weight
345kg
Working Width
170cm
Overall Width
195cm
Tractor HP Range
36-60HP
Linkage Type
3 point hitch, category 1
Tilling Depth
15cm
PTO Shaft
Included FREE of charge
Warranty
12 months manufacturer's warranty
Tractor CompatibilityCheck tractor fit for the Winton WPH series
Compatibility is based on standard tractor specifications, such as a 540RPM clockwise PTO, Type 1 or 2 linkage, and hydraulic spools where required.
ReviewsVerified Winton W‑PH170 Power Harrow reviews
1 review for the Winton W‑PH170 Power Harrow
1 review for all WPH Power Harrow models
Review Your Winton W‑PH170
Yes, great machine, definitely needs to be used with a slip clutch to prevent damage to blades. Can only be used when ground is dry or very near dry. Well built would give it a 5/5 rating.
