Winton 1.05m Tractor Stone Burier W‑SB105

The W-SB105 is the smaller of Winton's two stone buriers, built for compact tractors that can't pull the 1.25m W-SB125. At 1.05m working width and matched to a 20–28 HP tractor on Cat 1 linkage, it suits smallholders prepping paddocks, pastures and amenity ground for seed.

How it works in the field

20 PTO-driven blades till to a maximum depth of 12 cm. Heavier stones and debris drop underneath; lighter tilled soil rides on top. The rear mesh roller then runs over the surface and levels it, leaving ground ready for grass seed in a single pass.

Adjustable finish

The rear roller position adjusts easily, so you can set working depth and dial in the finish to suit the job — whether that's a tired paddock, a new lawn area, or rough ground after groundworks.

Driveline and safety

A shear-bolt PTO shaft is included as standard to protect the driveline if the machine bites something it shouldn't. An optional slip-clutch PTO upgrade is available — worth considering if you'd rather not replace shear bolts every time the burier gets overworked.

• Working width 1.05m, sized for the smaller end of the compact-tractor range
• Tractor range 20–28 HP on Cat 1 three-point linkage, 55 cm lower linkage width
• Maximum working depth 12 cm — flips stones under and lays soil on top in one pass
• 20 blades driven by PTO
• Adjustable rear mesh roller sets depth and levels the surface for seeding
• Shear-bolt PTO shaft included as standard
• Optional slip-clutch PTO upgrade available
• Weight 330 kg
