Topping larger paddocks for 30-60 HP compact tractors
Top long grass, weeds, brambles and light saplings on horse, sheep or alpaca grazing. At 1.8m wide, the Winton W‑TM180 covers larger paddocks in fewer passes - built for smallholders and compact-tractor owners whose smaller topper means too many laps.
OverviewEssential Winton W‑TM180 Topper Mower info
Mower Type Topper Mower
Tractor HP30 - 60 hp
Mower Position Manual Sideshift
Cutting Width 180 cm
Cutting Height50 - 250 mm
Weight 385 kg
Free PTO Shaft Included
Free Delivery Included
DescriptionWhy buy the Winton W‑TM180 Topper Mower?
When a narrower topper turns a paddock into an afternoon of laps, the W-TM180 is the answer. It's the widest deck in the Winton topper range, built for smallholders running larger horse, sheep or alpaca grazing who want fewer passes and a cleaner finish before stock go back on.
Built for bigger paddocks
The 1.8m working width covers ground quickly, and the 30–60 HP tractor range sets the floor — this one needs more pull than its smaller siblings. At 385 kg it's a heavier machine, so check your hitch and unloading arrangements before it lands.
Topping action and cut
2 blades on a direct-drive carrier give the classic rotary topping action, dropping cuttings in windrows along the skids. Direct drive draws less power than belt-driven decks. Cutting height runs from 5 cm for a tidier finish up to 25 cm for rank growth, set by unbolting and repositioning the side skids.
Hitching up
Mounts to a Cat 1 three-point linkage with a lower linkage width of 45–70 cm. A shear-bolt PTO shaft is in the box, so driveline protection is sorted from day one.
- 1.8m working width — the largest in the W-TM family, fewer passes per paddock
- 30–60 HP tractor range — bigger pull required than the narrower siblings
- Cutting height 5–25 cm, adjusted by repositioning the side skids
- 2-blade rotary topping action on a direct-drive carrier — windrowed cuttings along the skids
- Cat 1 linkage with 45–70 cm lower linkage width for small and compact tractors
- Shear-bolt PTO shaft included for driveline protection
- Stone guard fitted; multiple A-frame positions for setup flexibility
- 385 kg — pallet delivery requires unloading facilities on site
SpecificationsWinton W‑TM180 Topper Mower technical details
Brand
Winton Machinery
Reference (SKU)
W‑TM180
Weight
385kg
Working Width
1.8m
Linkage Type
Cat 1
Lower Linkage Width
45-70cm
Cuttng Range
5-25cm
Tractor HP Required
30-60hp
PTO Type
Shear Bolt PTO Shaft included as standard
Warranty
12 months manufacturer's warranty
Tractor CompatibilityCheck tractor fit for the Winton WTM series
Compatibility is based on standard tractor specifications, such as a 540RPM clockwise PTO, Type 1 or 2 linkage, and hydraulic spools where required.
ReviewsVerified Winton W‑TM180 Topper Mower reviews
2 reviews for the Winton W‑TM180 Topper Mower
20 reviews for all WTM Topper Mower models
Review Your Winton W‑TM180
Good and easy to deal with but wrong…
Good and easy to deal with but wrong PTO shaft supplied, all sorted amicably.
Ordering was easy good communication
Ordering was easy good communication. Good price too
I'm very pleased with my topper, it's had to work extremely hard, and has faired better than my tractor which now has a hole in the radiator. The only downside was I had to get the PTO shaft shortened to fit my little grey Fergie. Well worth the money.
The topper has been a huge success. I have a small compact tractor that I hook the topper to, to cut long grass. It cuts grass that is at least 50cms high. It's reasonable light but importantly, heavy enough to not be raised off the ground by the long grass. The tractor uses less fuel and it is way quicker than the flail mower I previously had. Quality wise...it is perfect quality, robust and the blades are heavy duty and can be easily sharpened with an angle grinder. On the lowest cutting height it cuts low enough for a smart path through long grass. It cuts rushes with no drop in rpm. Raising it on the three point hitch when turning is easy. Very pleased with it. 5 stars!!!!
